ADVANCED LASER POWDER BED SOLUTIONS

Industrializing new laser technologies for the next generation of laser powder bed fusion applications

Learn more

AMSENSE – Advanced Quality Control for metal laser powder bed fusion

AMSENSE is the ultimate platform for in situ sensing and analytics.  With up to 5 available advanced sensors, and over a dozen options for simple sensor inputs, AMSENSE is a comprehensive offering for quality control.  AMSENSE is offered on PANDA and as a 3rd party add-on to a variety of OEM machines.

AMSENSE provides:

  • Full access to all data
  • Plugin interface for analytic development and implementation
  • Industry-leading sensor technology
  • Modularity – sensors can be mix and matched to suit your application

Key sensors include:

  • Thermal Tomography
  • High speed spatter imaging
  • Recoat imaging
  • Long-wave Infrared imaging
  • Coaxial melt pool sensing
  • Simple sensors such as photodiodes, thermocouples, and others
AMSENSE provides multi-dimensional analysis of build performance.Implementing key analytics enables fast build analysis

PANDA™ 2.0 METAL 3D PRINTING SYSTEM

PANDA is the key platform for launching innovative laser powder bed additive technology, with the most powerful and flexible control software on the market.

Currently available with several laser technologies, including beam shaping and pulsed techniques.

PANDA is ideal for:

  • Advanced LPBF applications and parts that require better laser technology
  • Technology development
  • Materials research
  • Training and education

Key features include:

  • Multiple laser modalities
  • Multiple build size options
  • Configurable lasers/optics
  • The most flexible control software
  • Advanced process monitoring
  • Multi-material deposition
Open Additive's PANDA 2.0 Metal 3D Printing System

SYSTEM TECHNICAL DATA

PANDA can be configured in several base build configurations:

  • Small build configuration – 6 x 6 x 9.5 in (152 x 152 x 241 mm)
  • Large build configuration – 11 x 11 x 12.5 in (280 x 280 x 318 mm)
  • High temperature configuration – PANDA can be ordered with 200°C or 500°C preheat, configuration dependent
  • Custom configuration – PANDA is modular, custom sizes and designs are offered

More information:  See handout

PANDA features high-performance laser delivery components sourced from industry leaders:

Laser options

  • 500 W IPG Photonics 1070 nm fiber laser (air cooled)
  • 1000 W IPG Photonics 1070 nm fiber laser (includes chiller)
  • Single or dual laser configuration available
  • Specialty lasers may be integrated to meet customer needs

Optics options

  • SCANLAB intelliSCAN galvo scanner with F theta lens
  • SCANLAB fiberSYS “all-in-one scanning system” with dynamic focus control
  • SCANLAB varioSCAN with dynamic focus and melt pool imaging
  • Other options available…

More information:  See handout

PANDA includes Open Machine Control™ (OMC), a powerful standard software featuring:

  • User-friendly interface – intuitive GUI runs on included Windows 10 workstation
  • Full parameters control – set and adjust laser, hatch, contour, and all settings
  • Custom hatch strategies – Custom hatch strategies can be created directly or imported via dxf, cli, sli, or America Makes 4039
  • Advanced processing tools – Advanced logic tools and fully programmable process flow enable unprecidented experimental design options, including excel DOE import capability
  • Plugin capabilities – Independently create and implement custom code for closed-loop feedback, new hardware, or other tools
  • Perpetual license – never expires and includes 3 years of upgrades as available

More information:  See handout

PANDA can be configured with our optional AMSENSE® multi-sensor data collection and analysis platform, providing access to raw and processed data each layer through our proprietary software that runs on included Windows 10 computer. AMSENSE features several standard sensors as individual options, along with plugin interface allowing integration of future modules and user-developed/third-party code. In addition to optional AMSENSE modules, all PANDA systems include a Windows-based build camera for real-time viewing and recording of photos and videos as a standard feature.

Available AMSENSE modules:

  • Recoat imaging sensor – automatically records high-resolution images before and after each recoat
  • Thermal tomography sensor – high-resolution NIR imagery compiled into emissions maps for each layer
  • Spatter tracking sensor – detects, identifies, and tracks spatter events, and provides key spatter statistics
  • Longwave Infrared – LWIR video provides video of solid-state heat flow and background temperatures
  • Custom sensors/analytics – customer-specific or emerging capabilities may be integrated, as warranted

Note that AMSENSE can also be integrated on other industrial LPBF systems, beyond Open Additive systems.

More information:  See handout

Each PANDA includes:

  • Inert gas chamber – provides positive pressure environment (non-vacuum) for shielding gas (e.g., N2 or Ar)
  • Cross-bed flow – removes soot and debris to minimize defects; users may modify outlet and intake for application needs
  • Optics gas flow – provides flow across laser optics to prevent debris accumulation during the build
  • Integrated filtration – gas recirculation is provided by industrial two-stage filter for removal of debris particles
  • Safe passivation – filters can be rolled to passivation site without exposure to Oxygen
  • Sensors and control – oxygen levels are controlled by sensors and software with automated shutoff/alarm capabilities

Open Additive will provide starting parameters and available technical data at no extra charge for these common LPBF materials:

  • Stainless steel 316L and 17-4 PH
  • Aluminum alloy AlSi10Mg
  • Nickel-chromium alloy In718
  • Titanium alloy Ti-6Al-4V

Users always have the capability to see and modify these parameters, or create their own. The system places no restrictions on materials feedstock, though we can provide, if convenient.  We can work with prospective customers or system users to develop parameters and/or perform demonstration builds using most materials.

Open Additive offers these products to support your complete Metal AM operations:

Sieving station – Open Additive works with industry experts, such as Vorti-Siv or Kason to provide state-of-the-art options for powder sieving.

Portable powder vacuum – Open Additive offers standard explosion proof vacuum options, including vacuums intended for powder reclamation.

Build prep/removal cart – Customized for use with PANDA to assist with powder loading, build plate setup, and build plate removal. Includes fixtures and winch to mechanically assist in lifting completed builds.

Personnel safety package – Our personnel safety bundle includes two powered air-purifying respirators with hoods and filters, two ESD anti-static aprons, ESD anti-static reusable foot-heel straps, and box of nitrile gloves.

Facility safety package – Our facility safety bundle includes one Type D fire extinguisher for use on metal powders, one flammables storage cabinet (30-gal capacity), steel drum and tags/bags for disposal of contaminated items, and external sensor with alarm for monitoring oxygen level in the room.

Customers should always consult their own safety office and regulatory guidance. Users may always acquire support equipment through their own channels, and we are also happy to source other customer-specified support equipment, as necessary.

Standard service plan:

All equipment purchased with PANDA order (includes system, configuration options, and ancillary equipment) includes warranty, periodic servicing, and technical support for 12 months after installation. The system also comes with build plate, sample powder, and various hand tools for your use.

Extended service plan:

Extended service plans for up to 2 years or 3 years are also available at time of order.

System install and training:

Installation and training are included in system price. Shipping/travel are included separately.

OPEN PRICING MODEL

*NEW* 2022 Product/Pricing Guide

Contact us for questions and specific needs.

ADDITIONAL SERVICES

ABOUT OUR COMPANY

Open Additive is a manufacturer of innovative metal additive manufacturing (AM) systems, process monitoring solutions, and related products and services. Our driving focus is to increase adoption of the laser powder bed fusion industry by providing key advanced technology and equipment for a variety of user types, from academia to industry.  Our open nature is intended to empower end users and eviscerate the typical black box nature of additive machines and sensors.

Company pillars:

  • Open and honest communication — We help our customers understand the process, the machine, sensor data, and any questions about the industry.  Likewise, employees are partners with leadership and treated as such.
  • Innovation focus — We’re a technology-oriented small business that has created its own sensor and process technology, which is baked into our product offerings.
  • Be World Class — We strive to create excellent solutions for a growing and in demand field.  “That’ll do” is not good enough.
  • Community pride — We’re driven to serve our nation and community, and design and build all our products in the USA.

Open Additive, LLC, is registered in federal SAM system (DUNS 117237443).

Joe Sciabica – Chairman – in

Joe spent more than 30 years in the federal sector, rising to the Senior Executive Service. He spent much of his career leading complex technology-oriented organizations, including his role as Executive Director of the Air Force Research Laboratory. In the private sector, Joe has served in various leadership roles to transform high-tech firms in aerospace and defense, IoT and sensing, manufacturing, and other industries since 2015.

Alex Bosse – Member – in

Alex is Vice President at Battle Investment Group, supporting long-term growth and expansion for innovative small-to-medium businesses in aerospace, defense, intel, and communication markets. Alex also serves on Board of several other companies in the manufacturing sector.

John Middendorf, PhD – Director of Engineering / Technical Fellow – in

Dr. Middendorf has been developing the Open Additive brand since July 2014 and currently leads the design of the PANDA laser powder bed fusion platform, which aims to build robust, reliable machines that also advance the field through advanced process development, such as Selective Laser Ablation & Melting (SLAM) and Graded Alloy Processing (GAP).  In addition to machine design challenges, John also participates in technology and applications development at OA as a technical fellow.

Tom Spears, PhD – Director of Research & Technology – in

Tom leads technology development and product innovation in AM processing, sensing and analytics, and process control. He is highly experienced in the laser powder bed fusion arena, having served in technology and product leadership roles in both large OEM and small business settings since 2013. Tom has been lead or co-inventor on more than 20 awarded and submitted patents. His doctorate is in Physics from the University of Chicago.

John Van Oss – Director of Operations / Senior Engineer – in

John oversees many daily processes at Open Additive including supporting various financial and business operations. John has been highly integral in implementing several processes and practices OA uses to manage their multiple government and commercial projects. He is also a senior engineer and brings several years of engineering experience from his prior work in the commercial sector with Collins Aerospace in Troy, OH. In addition, John has a master’s in Mechanical Engineering from Wright State University.
